Shelly Presence Gen4
SH-SHELLYPRESW
Colour
White
Regular price
$143.00
SH-SHELLYPRESW
Colour
White
Regular price
$143.00
The Shelly Presence Gen4 is an advanced presence sensor that detects people even when they are sitting still, making it ideal for smarter lighting, climate control, security, and energy-saving automations.
Unlike traditional motion sensors that rely on movement, the Presence Gen4 can accurately identify real occupancy, helping prevent lights turning off while someone is working, reading, watching television, or simply sitting quietly. It can track up to six people simultaneously and supports up to ten custom detection zones, allowing automations to respond differently depending on where people are located within a room.
With support for Wi-Fi, Zigbee, Bluetooth, and Matter, the Presence Gen4 integrates easily into modern smart home systems. Adjustable sensitivity settings help minimise unwanted triggers from pets, children, or robot vacuum cleaners, while the built-in light sensor enables lighting automations based on both occupancy and ambient light levels.
Key Features
- Multi-protocol connectivity with Wi-Fi, Zigbee, and Bluetooth
- Matter certified
- Detects presence even when occupants remain still
- Tracks up to 6 people simultaneously
- Supports up to 10 configurable detection zones
- Covers areas up to 42m²
- Adjustable sensitivity settings
- Can ignore small movements from pets and robot vacuums
- Built-in ambient light sensor
- Reports dark, twilight, and bright light conditions
- Compact design for discreet installation
- Flexible placement on walls, shelves, desks, or wardrobes
- Ideal for lighting, HVAC, security, and automation systems
Specifications
|
Quantity |
Value |
|---|---|
|
Physical |
|
|
Size (HxWxD): |
64x41x26 mm / 2.49x1.59x1.02 inch (without stand) 73x41x37 mm / 2.87x1.61x1.46 inch (with stand) |
|
Weight: |
42 g / 1.48 oz (without stand) 85 g / 3.00 oz (with stand) |
|
Mounting: |
Freestanding base - for horizontal placement on shelves, tables, or wardrobes Adhesive tape - for tool-free installation on flat surfaces Screws and wall plugs - for installation on walls or other solid surfaces |
|
Shell material: |
Plastic with aluminum back |
|
Shell color: |
White Black |
|
Environmental |
|
|
Ambient working temperature: |
-20 °C to 40 °C / -5 °F to 105 °F |
|
Humidity: |
30 % to 70 % RH |
|
Max. altitude: |
2000 m / 6562 ft |
|
Electrical |
|
|
Power supply: |
5 VDC via USB-C, 1 A |
|
Power consumption: |
2.5 W (nominal) 3.5 W (max) |
|
Sensors, meters |
|
|
Light sensor: |
Yes |
|
Radar sensor: |
Yes |
|
Radio |
|
|
Wi-Fi |
|
|
Protocol: |
802.11 b/g/n/ax |
|
RF band: |
2401 - 2483 МHz |
|
Max. RF power: |
< 20 dBm |
|
Range: |
Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors |
|
Bluetooth |
|
|
Protocol: |
5 (LE) |
|
RF band: |
2402 - 2480 MHz |
|
Max. RF power: |
< 20 dBm |
|
Range: |
Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors |
|
Zigbee |
|
|
Protocol: |
802.15.4 |
|
RF bands: |
2405 to 2480 MHz |
|
Max. RF power: |
< 20 dBm |
|
Range: |
Up to 100 m / 328 ft indoors and 300 meters / 984 ft outdoors (Depends on local conditions) |
|
Microcontroller unit |
|
|
CPU: |
ESP-Shelly-C68F |
|
Flash: |
8 MB |
|
Firmware capabilities |
|
|
Schedules: |
20 |
|
Advanced schedules: |
Yes |
|
Webhooks (URL actions): |
20 with 5 URLs per hook |
|
Scripting: |
Yes |
|
MQTT: |
Yes |
|
UDP: |
Yes |
|
Encryption: |
Yes |
|
KVS (Key-Value Store): |
Yes |
|
Radar specific |
|
|
Radar frequency: |
60-64 GHz |
|
Object detection |
Yes, up to 6 objects (people) |
|
Wall mount coverage |
140 degrees horizontal (70 degrees on each side), 8 x 8 m 120 degrees vertical |
|
Corner mount coverage |
90 degrees (45 degrees on each side), 7 x 7 m |
|
Still detection |
Yes, up to 3 m |
Important: All electrical installation work must be performed by a qualified and licensed electrician. Failure to comply may void product warranties and breach electrical safety laws.
