Shelly Plus 2PM Smart Relay Switch - 2 Pack

PHYSICAL

Size (HxWxD): 37x42x16 ±0.5 mm / 1.46x1.65x0.63 ±0.02 in

Weight:

Mounting: Wall console

Screw terminals max torque: 0.4 Nm / 3.5 lbin

Conductor cross section: 0.5 to 1.5 mm² / 20 to 16 AWG

Conductor stripped length:5 to 6 mm / 0.20 to 0.24 in

Shell material: Plastic

Colour: Black

ENVIRONMENTAL Ambient temperature: -20 °C to 40 °C / -5 °F to 105 °F

Humidity 30 % to 70 % RH

Max. altitude 2000 m / 6562 ft

ELECTRICAL

Power supply: 110 - 240 VAC / 24 VDC ±10%

Power consumption: < 1.4 W

OUTPUT CIRCUITS RATINGS

Max switching voltage AC: 240 V

Max switching voltage DC: 30 V

Max switching current AC: 10 A (per channel), 16 A (total), 18 A (total peak)

Max switching current DC: 10 A

SENSORS, METERS

Temperature sensor: Yes

Voltmeter (AC)Yes

Ammeter (AC)Yes

RADIO

RF band: 2400 - 2495 MHz

Max. RF power: <20 dBm

Wi-Fi protocol: 802.11 b/g/n

Wi-Fi Range: Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions)

Bluetooth Protocol: 4.2

Bluetooth Range: Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions)

MCU

CPU: ESP32

Flash: 4 MB

FIRMWARE CAPABILITIES

Schedules: 20

Webhooks (URL actions): 20 with 5 URLs per hook

Scripting: mJS

MQTT: Yes

CoAP: No
